Reciprocating shuttle RGV

Uses: Since the rail-guided vehicle RGV can reciprocate and shuttle on the preset right-angle track, it can realize material handling at different positions in multiple stations. It is the carrier of the intelligent production line, with large load, fast running speed and flexibility. Strong, stable and reliable system.

Category： Warehouse Logistics

advantage:
● Strong conveying capacity, improve handling capacity
● It can be transported horizontally or vertically, supporting multiple machines to work at the same time
● Improve the overall efficiency of the three-dimensional warehouse system

specification

tandard load	1500 Kg
Standard height	450~800 mm
Standard running speed	160 m/min
Standard operating acceleration	0.5 m/s2
Horizontal positioning accuracy	3 mm
Standard conveying speed	16 m/min
Standard transfer mechanism	1/2
Standard operating temperature	-25 - 45℃
Ambient relative humidity	5 to 90% non-condensing
Standard guide frame structure	Side Roller/Guide Frame
Standard transfer mechanism	Roller type, chain type, lift fork type (customized)

* Other parameters can be customized
